Bronkhorst RS232 interface - Manual (Page 25)

BRONKHORST ®
Page 25 RS232 interface 9.17.027
46 F0 11110000
C 80 Parameter chained
Parameter index 16
Capacity unit
T 60 Parameter type ’string
N 10 Parameter index 16
47 07 Length of the answer 7 Bytes
48‐54
6D 6C 6E 2F 6D 69 6E
Parameter value converted from hex to ASCII, the values do
read : mln/min
55 71 01110001
C 00 Parameter not chained
Parameter index 17
Fluid name
T 60 Parameter type ’string’
N 11 Parameter index 17
56 0A Length of the answer 10 Bytes
57‐66
4E 32 20 20 20 20 20 20 20 20
Parameter value converted from hex to ASCII, the values do
read: N2
Total String :370302F1EC004D3632313233343541006D00555345525441470001AE1CD8CF3F800000F0076
D6C6E2F6D696E710A4E322020202020202020 \r\n
ASCII character “SPACE” (20 HEX) is returned for every empty space in the string.
3.10.5 Request measure
Request measure from node 3 process 1, type integer
Nr Byte Layout Description Description per block
0 :
Start
1 06 Length 6
2 03 Node 3
3 04 Command read
4 01 00000001
C 00 Process not chained (return)
Process 1
P 01 Process 1 (return)
5 21 00100001
C 00 Parameter not chained (return)
Parameter type 1
Process 1
Parameter number 0
Measure
T 20 Parameter type ‘integer’ (return)
N 01 Parameter index 1 (return)
6 01 ‐0000001 P 01 Process 1
7 20 ‐0100000
T 20 Parameter type ‘integer’
P 00 Parameter number (FBnr.) 0 (measure)
8 \r Carriage Return
End
9 \n Line Feed
Total String :06030401210120\r\n
Answer from node 3 process 1
Nr Byte Layout Description Description per block
0 :
Start
1 06 Length 6
2 03 Node 3
3 02 Command write
4 01 00000001
C 00 Process not chained
Process 1
P 01 Process 1 (receiving process)
5 21 00100001 C 00 Parameter not chained Parameter index 1
