XSAT Palm Link 2 Revision 0 MN/XPLINK.IOM
16
Chapter 13. Set Time / Date & Circuit ID Msg.
(CID)
<Main Menu><Stored Events / Alarms> (Ref. Figure 11)
XSAT#: (XSAT1/XSAT2) Sets the currently selected XSAT. The Currently Selected XSAT is
used in several menus (in 1:1 mode only) that allows the user to view or change most
parameters of the Currently Selected XSAT.
Note: This selection is not to be confused with the Online XSAT selection in the
Redundancy controller section.
Date: Displays the date of the Currently Selected XSAT.
Time: Displays the time of the Currently Selected
XSAT.
(NOW) button:
Displays the date and time of the Palm device.
Circuit Identification Message:
This is the CID message. The CID is displayed for the
Currently Selected XSAT.
(GET DATA) button:
Retrieves the date, time and CID message from the
Currently Selected XSAT.
(SEND DATA) button:
Sends the date, time, and CID message to the Currently
Selected XSAT.
(RETURN) button:
Returns to the Main Menu.
Figure 11
