Scoreboard Options 17
5.5 Light Strips
LED light strips are a common option for backstops to indicate the end of the period or to
show that that the shot clock time has expired. For installations that use backstop LED light
strips, refer to the LED End-of-Period Basketball Lighting Display Manual (ED-13652),
available online at
www.daktronics.com/manuals .
5.6 Changeable Captions
Team name and statistics caption kits contain hardware for one caption only and consist of an
upper caption retainer, a lower caption retainer, a changeable caption panel and screws.
The standard HOME and GUEST captions are applied directly to the face of the scoreboard.
Team name captions are on changeable panels that fit into retainers mounted above and
below the standard captions. If these retainers are not already present, attach the retainers
included with the caption kit. Caption kits are also available for certain statistics display
models to switch between basketball, volleyball, wrestling, and hockey modes.
Refer to Drawing A-1132576 in Appendix B for changeable caption installation instructions.
5.7 Time Outs Left (TOL) Digits
Certain scoreboards have the option to add a time outs left (TOL) digit for both the home
and guest teams. These digits are installed by simply unscrewing the blank face panel,
connecting and securing the digit, and manually applying the “T.O.L.” caption. Refer to
Drawing A-149030 in Appendix B for more information.
5.8 Double Bonus Indicators
All of the clock/score basketball scoreboards in this manual have the option to include
double-bonus indicators, which are factory installed. This option is illustrated in the electrical
and signal specification drawings attached to the product specification sheets listed in
Appendix A for each scoreboard model.
5.9 Team Name Message Centers & Electronic Captions
Team Name Message Centers (TNMCs) are programmable LED displays that allow users to
show custom Home and Guest names. TNMCs are typically ordered factory-installed but can
be field-mounted after the scoreboard is in place. Electronic captions, on the other hand, are
pre-programmed to only show specific labels to match the captions for a particular sport
mode, making it much simpler to switch between sports. For more information about TNMCs
or electronic captions, contact a Daktronics representative or refer to the service manual listed
in Section 1.3.
5.10 Goal Lights
For hockey installations involving optional goal lights, refer to the Indoor Hockey Goal
Lights Manual (ED-13358), available online at
www.daktronics.com/manuals .
