TOP VIEW
FRONT VIEW
BOTTOM VIEW
REAR VIEW
RIGHT SIDE
0'-6" [152mm]
9'-0" [2743mm]
3'-6"
[1067mm]
WP-2101
HOLE IN BOTTOM IS FOR
PASSING POWER AND SIGNAL
BETWEEN SECTIONS
LEFT SIDE
GUIDE HOLES, MAY BE USED
TO ROUTE POWER AND
SIGNAL INTO THE DISPLAY
KNOCKOUTS, MAY BE USED TO ROUTE
POWER AND SIGNAL INTO THE DISPLAY
0'-6" [152mm] 0'-6" [152mm]
0'-0 3/4" [19mm]
OBROUND @4
0'-1 5/8" [43mm]
INVERTED
CHANNEL DEPTH
THE CONCEPTS EXPRESSED AND DETAILS SHOWN ON THIS
DRAWING ARE CONFIDENTIAL AND PROPRIETARY. DO NOT
REPRODUCE BY ANY MEANS WITHOUT THE EXPRESS
WRITTEN CONSENT OF DAKTRONICS, INC.
COPYRIGHT 2014 DAKTRONICS, INC.
DAKTRONICS, INC.
AV
DRAWN: DATE:
SHEET JOB NO: REV
AQUATICS SCOREBOARDS
MECHANICAL SPEC; WP-2101
KDRAGT 20 MAR 14
P 1153 E 10 A
1=40
KDRAGT
1167914
00
