Section 1: Introduction
This manual explains the installation and maintenance of Daktronics Water Polo LED Scoreboards.
For additional information regarding the safety, installation, operation, or service of these displays,
refer to the telephone numbers listed in Section 5. This manual is not specific to a particular
installation. Project-specific information takes precedence over any other general information found
in this manual.
IMPORTANT SAFEGUARDS
 Read and understand all instructions before beginning the installation process.
 Disconnect display power when not in use or when servicing.
 Disconnect display power before servicing power supplies to avoid electrical shock.
Power supplies run on high voltage and may cause physical injury if touched
while powered.
 Do not modify the scoreboard structure or attach any panels or coverings to the
scoreboard without the express written consent of Daktronics.
 Do not disassemble control equipment or electronic controls of the display; failure to
follow this safeguard will make the warranty null and void.
 Do not drop control equipment or allow it to get wet.
1.1 Scoreboard Controllers
Daktronics water polo scoreboards are designed for use with the All Sport ® 5000 control
consoles and OmniSport 2000 timing consoles. Both controllers use keyboard overlays (sport
inserts) to control numerous sports and scoreboard models. Refer to the following manuals
for operating instructions:
 All Sport 5000 Series Control Console Operation Manual (ED-11976)
 OmniSport 2000 Timing Console Operation Manual (ED-13312)
These control console manuals are available online at www.daktronics.com/manuals .
1.2 Specifications Label
Power specifications as well as serial and model number information can be found on an ID
label on the display, similar to the one shown in Figure 1.
Please have the assembly number, model number, and the date manufactured on hand when
calling Daktronics customer service to ensure the request is serviced as quickly as possible.
Knowing the facility name and/or job number will also be helpful.
Figure 1: Specifications Label
