2-8 Basic Operation
If you suspect interference from a nearby Daktronics system, press <CLEAR> at the
“RADIO SETTINGS” prompt to change the channel number.
Typically all Multiple Controller systems will use channel 1 for the first controller.
All other controllers will use sequential channel settings (2-8). The table on the
following page describes broadcast group and channel settings.
LCD Display Action
The LCD will toggle
these screens
The bottom line shows default
settings.
RADIO SETTINGS
BCAST Y CHAN XX
Enter to accept
Clear to modify
bcast group 1
Radio chan 01
The LCD shows the current radio settings along with a
prompt to accept or modify these values.
If the radio settings are correct, press <ENTER>.
If these values are incorrect, press <CLEAR>
If <CLEAR> is pressed to modify the radio settings, the
LCD at the left is shown, allowing edit of the Channel
or Broadcast group setting.
Edit the Broadcast Setting. Use the number keys to
enter the desired broadcast group and press <ENTER>
to accept.
Broadcast Group Setting
1- Use this setting for all multiple controller with
single broadcast group setups.
The asterisk will move to the channel setting.
Use the number keys to edit this value and press
<ENTER> to accept. Edit the channel number
to the desired value and press <ENTER> to
accept.
Channel Setting
1-8 Channels that may be used with broadcast
channel 1. The channel switch on the receiver
must match this value and only the Broadcast 1
(BCAST1) jumper must be installed.
Multiple Controller with Multiple Broadcast Systems
Channel Setting
Typically all multiple controller systems will use Broadcast Group 1 Channel 1 for
the first controller in Broadcast Group 1 and Broadcast Group 2 Channel 1 for the
first controller in Broadcast Group 2. All other consoles in each group are added
sequentially, using channels 2-4.
