Hockey Operations

8-1

Section 8:

Hockey Operations

Sport Insert LL-2468 (Code 04)

Codes used by the All Sport 3000 console to replace the All Sport 2500 console are as
follows:

461


Refer to Appendix C.5 for a list of the codes of the All Sport 2500 console and which code
for the 3000 system takes its place.

Section 16:

Reference Drawings:

Insert, Hockey/Lacrosse A/S3000 Series ................................. Drawing A-129368

Block

Diagrams,

A/S5000/3000 Hockey ................................... Drawing A-124689

The sport insert and block diagram drawings are located in Appendix A.

Refer to the information in Section 2: Basic Operation to start the console and use the sport
insert. Read Basic Operation carefully to fully understand the following operation
instructions. The hockey insert drawing, A-129368, displays the function for each key on the
All Sport 3000 series consoles during hockey and lacrosse mode. The block diagram
drawing, A-124689, displays the installation of the All Sport 3000 series control consoles to
the main scoreboard and other Daktronics products.

If you lose or damage an insert, use a photocopy of the insert until you can order a
replacement.

If you do not know the code number to enter for your scoreboard, refer to Appendix B in this
manual. If you do not know the model number of your scoreboard, refer to the installation and
maintenance manual provided with the scoreboard.

8.1 Hockey

Keys

Enable Penalty Clocks

Press <ENABLE PENALTY CLOCKS> to allow the penalty clocks to count when
the main clock is on.

Disable Penalty Clocks

Press <DISABLE PENALTY CLOCKS> to disable the penalty clocks from
counting when the main clock is on.

Minor/Major Penalty

Use <MINOR PENALTY> and <MAJOR PENALTY> to enter the penalty time
when you select <PLAYER PENALTY>. (Refer to the Player Penalty subsection
that follows.)
