Chapter 3 BIOS Setup
Chapter 3
Ipv4 PXE Support
When enabled, Ipv4 PXE boot supports. When disabled, Ipv4 PXE boot option will not
be created.
Ipv6 PXE Support
When enabled, Ipv6 PXE boot supports. When disabled, Ipv6 PXE boot option will not
be created.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
 System Agent (SA) Confi guration
 PCH-IO Confi guration
Save & Exit Advanced Boot Security Main Chipset
System Agent (SA)
Parameters
System Agent (SA) Configuration
This section is used to configure the parameters of System Agent.
Check to enable VT-d
function on MCH.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
System Agent Bridge Name
System Agent RC Version
VT-d Capability
VT-d
 Graphics Confi guration
 NB PCIe Confi guration
 Memory Confi guration
Haswell
1.5.0.0
Supported
[Enabled]
Chipset
VT-d
Enables or disables the VT-d function on MCH.
Chipset
This section configures relevant chipset functions.
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
