DR Power Power Wagon 4 x 2 8hp B&S (April 2002 - March 2004) - Manual (Page 23)

Page 23
Checking the Bolts and Nuts:
Be sure to check for loose bolts and nuts and tighten them when necessary.
Be sure to check the wheel hub bolts after using the vehicle for 100 hours or on bi-weekly
basis.
Torque values of the bolts are given as follows: .
Battery Information:
Your DR® Powerwagon™ 4 x 2 has an automotive style 12 volt lead-acid battery.
Maintenance on this battery is similar to that of your car.
Always disconnect the spark plug wire before servicing.
Caution: Always wear eye protection when servicing the battery.
Caution: Always wear acid resistant gloves when servicing the battery
Caution: Never smoke or allow others to smoke or be near any other sources of
ignition when servicing the battery.
• Remove the battery cell cap. Add distilled water to the cell or cells if needed. Replace the
cap.
Important: Remember that battery acid is corrosive and can cause burns. Your battery and
terminals and posts should be cleaned periodically with a mild solution of baking soda and
water, and then rinsed thoroughly with plain water.
Specification Torque
3/8"-16 NC (Ordinary) 30 foot-lbs.
3/8"- 16 NC (Medium) 32 foot-lbs.
7/16-14 NC (Medium) 35 foot-lbs.
M14xP2.0 (Rod Joint) 70 foot-lbs.
