Epiphan VGA Printer - Manual (Page 43)

4. VGA Printer Web admin interface Configuring the Ethernet Bridge For Use if You Have Only
User Guide Page 43
3 Log into the Web admin interface.
If you have been able to assign the VGA Printer an IP address
log in using that IP address. Otherwise, use the following
steps:
• Change the IP address of the PC connected to ETH 1 to:
IP Address: 192.168.255.249
Subnet Mask: 255.255.255.252
Follow the instructions for your operating system. If your
operating system supports adding more than one IP
address, then you can add this IP address as a second IP
address instead of changing the current address.
• Start a web browser on the PC and browse to:
http://192.168.255.250
• Enter the following:
User Name: admin
Password: (no password required)
• Press Enter to log into the Web admin interface.
4 In the Ethernet Bridge section, select Enable.
5 Select Change Ethernet Bridge Configuration.
6 Select Continue.
7 Scroll down the Web admin interface to the Reboot the
system section and select Reboot. Then select Continue.
It takes a few minutes for the device to reboot.
8 Scroll down to Change IP Address.
9 Set How to obtain IP address to Use static address.
10 Enter the following network settings:
IP: 192.168.10.101
Mask: 255.255.255.0
Gateway: 192.168.10.200
DNS server: (leave blank)
