Display:
ENTER
PASSWORD?
Toggle the black OPEN-CLOSE knob: → OPEN (YES) → Release
(Following screens assume default password = 100)
Display:
[0] 0 0
DIGIT 1 - OK?
Toggle the black OPEN-CLOSE knob: → CLOSE (NO) → Release
Display:
[1] 0 0
DIGIT 1 - OK?
Toggle the black OPEN-CLOSE knob: → OPEN (YES) → Release
Display:
1 [0] 0
DIGIT 2 - OK?
Toggle the black OPEN-CLOSE knob: → OPEN (YES) → Release
Display:
1 0 [0]
DIGIT 3 - OK?
Toggle the black OPEN-CLOSE knob: → OPEN (YES) → Release
Display:
PASSWORD IS 100
OK?
Toggle the black OPEN-CLOSE knob: → OPEN (YES) → Release
Display:
CHANGE VALVE
SETUP?
Setup mode has been enabled.
a CAUTION: Most changes made from this point forward will be saved in the actuator whenever exiting the Setup
Menu dialogue or whenever the red REMOTE-STOP-LOCAL knob is moved from its STOP position.
If the actuator detects no knob activity for 15 minutes, then it will force an actuator reset and most changes will be
saved at that time.
If it is desired to exit the Setup Menu dialogue after changes have been made but without saving the changes, then
power must be removed from the actuator BEFORE leaving the Setup Menu dialogue.
