Electrical Safety Analyzer
How to Use the 1-to-10 Adapter
57
When you do an applied parts test with the AAMI/NFPA-
99 standard, the normal connections of RA, LL, LA, and
RL are made to their related input jacks. Four adapters
from the Universal Snap to Banana Adapter set will be
necessary for the first four connections. The other chest
leads are connected to the Adapter and the common lead
from the Adapter is connected to the V1 jack (5
th jack) of
the Product. See Figure . This configuration lets you
isolate the RA, LL, LA, and RL leads from each other and
the other chest leads, which are shorted together, while
the Product does the leakage tests.
