Installation
Mounting
2
2-1
Section 2
Installation
2.1 Mounting
The mounting bracket (102007) can be attached to any convenient vertical mounting surface. Before
mounting the bracket to the wall, ensure that the six-foot converter power cord will reach the nearest
power outlet.
The wall-mounting bracket comes supplied with double-sided foam tape already attached. Peel off the
protective paper covering and apply firmly to the mounting surface.
Once the unit is in place, the bracket cannot be
moved or removed without destroying the tape.
Make sure of your installation site before applying
the tape or mounting the unit. Mounting holes are
also provided if you wish to mount the unit using
screws.
2.2 Power
Connect the 100-foot cable to the Primalarm and the Primalert using the alarm jacks (the small jack
located on the bottom of both units). The plug on the end of the converter power cord (six feet long)
should be inserted into the power jack (the larger jack located on the bottom of the unit), then the
converter should be plugged into a wall outlet.
2.3 Optional Power
In case operation of the Primalert on a source of 12 to 16 VDC power, such as a storage battery, is
desired, the converter plug supplies this voltage. The plug is a Switchcraft No. 50760, or equivalent, with
the sleeve negative and the tip positive. The current drain at background radiation levels is about 10 mA,
and about 250 mA at full alarm levels.
CAUTION
