System Information
This sub-menu is used to set up the standard BIOS features, such as the date, time, floppy drive
and so on. Use the arrow up/down keys to select an item, then use the <+> or <-> keys to change
the setting.
► Time (hh:mm:ss)
This item allows you to configure the desired time. Use [ENTER] to enter the setting, then use
[TAB] to move forward a field. Use [+] or [-] to input the value.
The three fields of the setting are <hour> : <minute> : <second> respectively.
► Date (mm:dd:yy)
<weekday><month><date> <year> format.
Day—weekday from Sun. to Sat., this message is automatically displayed by BIOS (Read
Only).
Month—month from 1 to 12.
Date—date from 1 to 31.
Year—year, set up by users.
Use [ENTER], [TAB] or [SHIFT-TAB] to select a field. Use [+] or [-] to input the value.
► SATA Port 1 / SATA Port 2 / SATA Port 3 / SATA Port 4 / eSATA Port
When OnChip SATA Type is set to [Native IDE], while entering setup, BIOS automatically
detects the presence of SATA devices.
SATA Port 1 is the lower SATA port of SATA1_SATA2 of the motherboard.
SATA Port 2 is the upper SATA port of SATA1_SATA2 of the motherboard.
SATA Port 3 is the lower SATA port of SATA3_SATA4 of the motherboard.
SATA Port 4 is the upper SATA port of SATA3_SATA4 of the motherboard.
E-SATA Port is on the motherboard.
► Halt On
This category determines whether or not the computer will stop if an error is detected during
powering up.
[All Errors] : All errors can result in system halt.
[All Errors But...] : All errors but keyboard or mouse can result in system halt. The halt condi-
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
System Information
System Time
[11 : 59 : 49]
Help Item
System Date
[Sun 04/26/2009]
Use [Enter], [TAB]
► SATA Port 1
[Not Detected]
or the a torrow keys to
► SATA Port 2
[Not Detected]
select a field.
► SATA Port 3
[Not Detected]
► SATA Port 4
[Not Detected]
Use [+] or [-] to
► eSATA Port
[Not Detected]
configure the system
time.
Halt On
[All Errors, But ...]
Keyboard
[Disabled]
Mouse
[Disabled]
System Overview
BIOS Information
Mainboard Model : Cinema
BIOS ID
: 912F1P01
BIOS Build Date :06/01/09
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F2/F3:Change Colors
F9:Optimized Defaults
