PCIe Port #6
► Gen2 High Speed Mode
This item is used to select the Generation II speed mode of PCI Express slots. Select [Auto],
RC will only advertize Generation II capability; Select [Software Initiated], the speed mode is
determined by software initiated; Select [Advertised RC], the speed mode is determined by RC
initiated; Select [Disabled], BIOS will turn off Generation II speed mode of PCI Express slots.
► Link ASPM
This item is used to select the link mode between ASPMs.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
PCIe Port #6 Configuration
Gen2 High Speed Mode Help Item
Link ASPM [Disabled]
Enabled Gen2 speed
based HW or SW
support
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F2/F3:Change Colors F9:Optimized Defaults
[Auto]
The item of the PCIe Port #7 / 9 / 10 is the same of the PCIe #6.
