Description of the MCA Communication DLL

MCA Mode functions:

Name

MMCA_SET_GENERAL_MODE

Description

The function sets the general MCA527 mode.

Declaration

ERROR_FLAG CALLBACK MMCA_SET_GENERAL_MODE(unsigned short unMode);

unMode

General MCA527 mode (see CMD_SET_GENERAL)

Return value

See MCA_COMM function

Name

MMCA_SET_MODE_MCA

Description

The function sets the acquire mode to Multi-Channel Analyser.

Declaration

ERROR_FLAG CALLBACK MMCA_SET_MODE_MCA();

Return value

See MCA_COMM function

Name

MMCA_SET_MODE_MCS

Description

The function sets the acquire mode to Multi-Channel Scaler. The MCS input remains unchanged.

Declaration

ERROR_FLAG CALLBACK MMCA_SET_MODE_MCS();

Return value

See MCA_COMM function

Name

MMCA_SET_MODE_MCS_TTL

Description

The function sets the acquire mode to Multi-Channel Scaler and the MCS input to “extern TTL”.

Declaration

ERROR_FLAG CALLBACK MMCA_SET_MODE_MCS_TTL();

Return value

See MCA_COMM function

Name

MMCA_SET_MODE_MCS_ICR

Description

The function sets the acquire mode to Multi-Channel Scaler and the MCS input to “Input Rate”.

Declaration

ERROR_FLAG CALLBACK MMCA_SET_MODE_MCS_ICR();

Return value

See MCA_COMM function

Name

MMCA_SET_MODE_MCS_DISCR

Description

The function sets the acquire mode to Multi-Channel Scaler and the MCS input to “LLD/ULD”.

Declaration

ERROR_FLAG CALLBACK MMCA_SET_MODE_MCS_DISCR();

Return value

See MCA_COMM function

MCA Clear functions:

Name

MMCA_CLEAR_MEMORY

Description

MCA166: The acquisition is stopped and the spectrum is cleared.
MCA527: The acquisition is stopped and the spectrum, the real time and the dead time are cleared.

Declaration

ERROR_FLAG CALLBACK MMCA_CLEAR_MEMORY();

Return value

See MCA_COMM function

9
