i
READ BEFORE USING THE KBM®-28 BEVELLER
IMPORTANT NOTES:
All machine operators must be familiar with the Safety Instructions on
pages 1 & 2 of this manual before attempting to use the KBM
®
-28 Beveller.
The machine must be set in accordance with the “Bevel Setting” section of
this manual (pages 11 - 16) prior to bevelling or machine / cutter damage
will occur.
Bevelling should always be done conservatively. No more than 70% of the
machines total bevelling capacity may be bevelled in a single pass. Multi-
pass bevelling is required in such instances.
As the bevelling capacity of the machine is reduced on higher tensile
materials, no more than 50% of the machines total bevelling capacity
should be bevelled in a single pass when bevelling high tensile steel and
stainless steel.
TABLE OF CONTENTS
SAFETY INSTRUCTIONS .................................................................................................................................. 1
KBM®-28 PLATE EDGE BEVELLING MACHINE DETAILS .............................................................................. 3
MACHINE SPECIFICATIONS .................................................................................................................... 3
BEVELLING CAPACITY ............................................................................................................................. 5
GENERAL DESCRIPTION ................................................................................................................................. 6
INTENDED / FORESEEN USAGE ..................................................................................................................... 6
LIFTING (HOISTING) .......................................................................................................................................... 7
INSTALLATION ................................................................................................................................................... 8
ELECTRICAL CONNECTION .................................................................................................................... 8
MECHANICAL INSTALLATION ............................................................................................................... 10
OPERATION ..................................................................................................................................................... 11
BEVEL SETTINGS ................................................................................................................................... 11
22.5º BEVEL ARRANGEMENT ................................................................................................................ 17
30º BEVEL ARRANGEMENT ................................................................................................................... 17
37.5º BEVEL ARRANGEMENT ................................................................................................................ 18
45º BEVEL ARRANGEMENT ................................................................................................................... 18
55º BEVEL ARRANGEMENT ................................................................................................................... 19
ROOT FACE SCALE EXAMPLES ........................................................................................................... 19
PREPARATION FOR SELF PROPELLED OPERATION ........................................................................ 20
