Applied Connection
Connection to Computer
Basic Connection
1. Use 220 V or 110 V. (Free Voltage)
2. Connect monitor and computer via computer cable (See figure )
3. Switch on power to monitor and computer.
4. Installation is finished.
1. Connect the adapter to "12V DC" input terminal.
2. Connect the computer cable to PC.
3. Connect audio output to Audio In (Stereo).
4. Connect headphone or earphone to H-Phone terminal.
12V DC connection
terminal
Computer cable
For PC
For Macintosh
Use adapter.
Adapter for Macintosh (Optional)
Refer to the table on the rear side of
the optional Macintosh adapter and
adjust DIP switch by the resolution of
the monitor.
