Hoist Fitness RS-1201-A - Manual (Page 11)

51
60
60
6
48
48
51
FRAME ASSEMBLY
NOTE:
- WRENCH TIGHTEN HARDWARE.
- SOME PARTS MAY HAVE BEEN
REMOVED FOR CLARITY.
RS-1201-A ASSEMBLY
OWNER'S MANUAL
PAGE 10
PROPERLY INSTALLED VIEW
NOTE:
BE SURE BOLTS (60) ARE
INSTALLED SO BOLT HEADS
FIT INTO HEX BOLT LOCKS,
AS SHOWN.
PROPERLY INSTALLED VIEW
