Hoist Fitness RS-1201-A - Manual (Page 21)

ITEM NO. PART NUMBER DESCRIPTION QTY.
2 026-01X3750 RIGHT HANDLE ASSEMBLY 1
3 026-01X3751 LEFT HANDLE ASSEMBLY 1
4 026-01X3800 PRESS ARM ASSEMBLY 1
5 026-01X2397 PRESS ARM LINK ASSEMBLY 1
6 026-01X3798 SEAT ASSEMBLY 1
7 026-01X3797 MAIN BOTTOM TUBE ASSEMBLY 1
8 026-01X2559 REAR LINK ASSEMBLY 1
9 026-01X3714 FRONT UPRIGHT ASSEMBLY 1
10 026-01X2581 CROSS MEMBER ASSEMBLY 1
11 026-01X2402 FOOT PLATE ASSEMBLY 2
12 022-01PD2056 SEAT PAD ASSEMBLY 1
13 026-01X3176 UPPER CROSS MEMBER ASSEMBLY 1
14 026-01X3433 ADJUSTABLE ROLLER PAD MOUNT 1
15 026-01X2784 PULL-PIN ASSEMBLY 1
16 010-01C0358 CABLE ASSEMBLY RS-1201-A - 137.41 LG. 1
18 014-0012013 BEARING: BALL BEARING Ø2.44" O.D. X Ø1.18" I.D. 2
19 014-0101005 BUSHING: OILITE FLANGED Ø1.38" O.D. X Ø1.00" I.D. X .81" LG. 2
20 014-0012014 BEARING: FLANGELESS - 25mm I.D. 16
22 014-0014002 3/8-16 FLUSH MOUNT INSERT 4
23 016-0201041 END CAP: 3.00" X .06" WALL (BLACK) 1
24 018-0001003 CABLE PULLEY: Ø4.50" 2
25 019-0001001 PLUG BUMPER 5
26 026-01F0256 BACKING PLATE 1
27 026-01M0238 FLATHEAD CAP Ø2.00" ALUM. 2
28 026-01M2647 END CAP: DOMED Ø 2.75" O.D. 2
29 026-01M2360 SHAFT - 25mm X 4.71" LG. 5
30 026-01M2043 BOLT STAND-OFF 2
31 026-01M1103 THREADED CABLE ANCHOR Ø1.00" O.D X 2.50" LG. 1
32 026-01M2629 SHAFT - 1.181" X 4.71" LG. 1
33 026-01M0932 ALUMINIUM CAP: Ø1.25" ID 2
35 026-01M0983 45LB COUNTER WEIGHT 1
36 026-01M1032 SHAFT 1.00" X 2.97" LG. 1
37 026-01P3021 BACKING PLATE 1
38 026-01P2475 FRONT LINK PLATE 1
39 026-01P2650 CABLE SHIELD 1
40 026-01P2653 'H' PLATE 1
PART LIST
PAGE 20
OWNER'S MANUAL
RS-1201-A ASSEMBLY
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
