Hoist Fitness RS-1201-A - Manual (Page 14)

6
51
48
5
61
- SOME PARTS MAY HAVE BEEN
REMOVED FOR CLARITY.
NOTE:
- WRENCH TIGHTEN HARDWARE.
FRAME ASSEMBLY
PAGE 13
OWNER'S MANUAL
RS-1201-A ASSEMBLY
PROPERLY INSTALLED VIEW
NOTE:
BE SURE BOLT (61) IS INSTALLED
SO BOLT HEAD FITS INTO HEX BOLT
LOCK, AS SHOWN.
