INSTALLATIONS
12
MB900-R User’s Manual
[
Connectors on MB900-R
The connectors on MB900-R allows you to connect external devices
such as keyboard, floppy disk drives, hard disk drives, printers, etc. The
following table lists the connectors on MB900-R and their respective
functions.
ATX1: 24-pin ATX Power Connector ................................................. 14
ATX2: ATX 12V Power Connector .................................................... 14
MB900-R Edge Connectors ................................................................. 14
CN1: PS/2 Keyboard and PS/2 Mouse Connectors ............................. 15
CN2, J2, J7, J8: COM1/2/3/4 Serial Ports ........................................... 15
CN3: Parallel Port Connector .............................................................. 16
CN4: VGA CRT Connector ................................................................. 16
CN5: Audio Connector ........................................................................ 17
CN6: 10/100 RJ-45 and USB0/1 Connector ........................................ 17
CN7: GbE RJ-45 and USB2/3 Connector ............................................ 17
CN11, CN10: SATA0/1 Connector ..................................................... 17
J1: Digital I/O Connector (4 in, 4 out) ................................................. 18
J3: Audio Front Header ....................................................................... 18
J5: USB4/USB5 Connector ................................................................. 18
J6: USB6/USB7 Connector ................................................................. 18
J9: Wake On LAN Connector .............................................................. 19
J10: System Function Connector ......................................................... 19
J11: IrDA Connector ............................................................................ 19
FAN1: CPU Fan Power Connector ..................................................... 19
FAN2, FAN3, FAN4: Fan Power Connectors ..................................... 20
IDE1: Primary IDE Connectors ........................................................... 20
PCIE_1: x16 PCI Express Slot ............................................................ 20
PCIE_2: x1 PCI Express Slot .............................................................. 20
PCI1, PCI5: PCI Slots .......................................................................... 20
CN12: CF Socket ................................................................................. 20
