BIOS SETUP
32
IB704 User’s Manual
PC Health Status
This section shows the parameters in determining the PC Health Status.
These parameters include temperatures, fan speeds and voltages.
Phoenix - AwardBIOS CMOS Setup Utility
PC Health Status
CPU Warning Temperature
Disabled
ITEM HELP
System Temp.
45°C/113°F
Menu Level >
CPU Temp
30°C/86°F
Vcore(V)
1.18 V
Vmem
2.57V
Vcc3(V)
3.39V
+5V
5.13 V
+12V
11.12 V
-12V
-12.19 V
VBAT
3.21 V
5VSB
4.92 V
CPU Warning Temperature
This field allows the user to set the temperature so that when the
temperature is reached, the system sounds a warning. This function can
help prevent damage to the system that is caused by overheating.
Temperatures/Voltages
These fields are the parameters of the hardware monitoring function
feature of the motherboard. The values are read-only values as monitored
by the system and show the PC health status.
