USB 2.0 Intel
®
HM76 integrated USB 2.0 host controller:
1. 4ports in the rear panel (2x USB2.0; 2x USB3.0)
2. 2 ports (USB3.0) via edge golden-finger for connector ID912
3. 2 ports via onboard Mini-PCIE
4. 2 ports via edge golden-finger for connecting with ID912
5. 1 port (with open collector) via edge golden-finger for connecting with
IP931
**Total 11 x USB 2.0 ports**
USB 3.0 Intel
®
HM76 integrated USB 3.0 host controller:
1. 2 ports in the rear panel
2. 2 ports
**Total 4 x USB 3.0 ports**
Serial ATA Ports Intel
®
HM76 built-in SATA controller
Supports 2x SATAIII for HDD
Supports 1x SATAII for mini PCIE and mSATA
Supports 1x SATAII for CFast slot
SATA power on mainboard
LPC I / O Fintek F81866AD-I
- COM #1 (RS232/422/485 jumper-less) support ring-in with power
@500 mA (selectable for 5V or 12V)
- COM #2 (RS232/422/485 jumper-less) support ring-in with power
@500 mA (selectable for 5V or 12V)
- COM #3 (RS232 only)
- COM #4 (TTL for daughter board usage) thru golden finger to
expansion module
- COM #5(TTL for MCU usage) thru golden finger to expansion
module
[Hardware Monitor]
2x Thermal inputs
2x Voltage monitoring
Expansion Slot - Mini PCI-e socket x 1, Full-sized type, reserved one mounting hole
for half-sized type, [USB device and mSATA support]
- Mini PCI-e socket x 1,Full-sized type [USB device support]
Digital IO 4 in (TTL)& 4 out (open collector) 5Vcc 1A and Ground [@ terminal
block 1x10 180D.] ECH350R-10P/EC350V-10P
Edge Connector DIV-I connector x1
DB9 x 3 for COM1/2(RS-232/422/485) COM 3 (RS-232 only)
10pin terminal block for Digital I/O x1
RJ45 x2 for GbE LAN
USB connector x 4; USB1/2 USB2.0 only; USB3/4 USB3.0
Line-out microjack x 1
Mic-in microjack x 1
CFast slot x 1
Onboard
Header/Connector 2 ports x SATA III
4 pins power connector x 2 for SATA HDD
2x5 pins pitch 2.0mm header x 1 for LPC (Debug purpose only)
Mini PCI-e(1x) connector x 1 [Full-sized]
Mini PCI-e(1x) connector x 1 [Full-sized]
Box header 5pins for smart battery interface x 1
2x10-pin for 12V 5V 3.3V ATX power connector right angel type x 1
1x3 box header for CPU fan
1x3 box header for system fan
