VH7i
7" HDMI LCD Monitor with IPS Panel QUICKSTART GUIDE
LOCK
MENU EXIT/
ASPECT
HDMI
OUT
HDMI
IN
4 3 10
8 9 10 7 10 12 6 5
2 1
F1 F2
ON OFF
www.ikancorp.com 713-272-8822
1
Menu Button. Scroll Wheel
Used to enter and navigate menu
EXIT/Aspect
Used to exit the menu. When outside of the
menu used to change scrrecn aspect ratio
Function 2
Function Key actions are selected in the menu
Function 1
Function Key actions are selected in the menu
Power Switch
Power ON/OFF
HDMI Input Terminal
DC 7-24v Power Terminal
Standard DC Connection
HDMI Output Terminal
USB terminal
For factory service use only
3.5mm Head Phone Output
1/4-20 Threaded Insert (On top & Bottom)
DV Battery Plate Slot
Mounting ikan DV Battery Plate
2
3
4
5
6
8
7
9
10
11
12
