Replacement.
Clean the bores of the sprocket, bushing, and shaft. Do
not oil these surfaces. Place one drop of oil on each
screw. Insert the bushing into the sprocket. Align the
two sprocket holes A (with threads) and the bushing
holes A (with threads). Thread the screws into the holes
A.
Place the key on the shaft and slip the entire sprocket
and bushing onto the gear motor or conveyor shaft.
Replace the drive belt. Align the sprockets and drive
belt and alternately tighten the screws.
Removal and replacement of sight glass (porthole).
Drain the appropriate tank.
Remove the 4 screws and lock nuts and remove the
entire assembly from the outside of the tank. Clean the
tank surfaces.
Replace the parts of the assembly per Fig. 6-12. Use
silicone sealant on each screw, behind the lock nut.
Tighten the screws until snug. Note that the stainless
steel ring is NOT designed to touch the tank wall when
screws are tightened.
Fill the tank and check for leaks.
Removal and replacement of liquid level float switch.
Turn off dishwasher power at the main disconnect
switch. Drain the appropriate tank.
Disconnect the two switch electric wires. Remove the
hex nut and remove the switch from the inside of the
tank.
Clean the tank surfaces. Replace the switch, with the
rubber washer on the inside of the tank. See Fig. 6-13.
Fill the tank and check for leaks.
