Assembly Instructions
Please read these assembly instructions thoroughly before attempting to assemble the CA17 digital piano.
Please ensure that two or more people work on assembling the CA17 digital piano, especially when lifting the
main body of the instrument onto the stand.
Included parts
Before attempting to assemble the CA17 digital piano, ensure that all parts below are included.
A Phillips-head screwdriver (not included) will also be required in order to assemble the instrument.
Main body
Side panel (left)
Pedal board
(including support bolt)
Front under board
Back board
Side panel (right)
Screw set
Screw (with washer) x 4
Flat headed screw (12 mm) x 2
Tapping screw (black, 30 mm) x 4
Tapping screw (black, 20 mm) x 4
Tapping screw (silver, 16 mm) x 4
Headphone hook set
Headphone hook
Mounting screws (14 mm) x 2
C
B
E
A
D
F
Power cable
AC/DC adaptor
