6. MENU Buttons
The MENU buttons allow access to the edit parameters in the MP6. This collection
of settings together with other editable parameters can be stored as a SETUP.
The MP6 provides 256 SETUPs, and all are user programmable.
A SETUP consists of four zones. Each zone can be set as Internal, External or Both
individually. Inside each of the four zones, a multitude of features and effects
can be programmed and combined together into one exciting SETUP.
A total of 256 SETUPs may be programmed in this way.
The menu consists of Internal parameters, External parameters and Common
parameters.
Common parameter affect all zones. If a zone is set as Both, both the Internal
parameters and External parameters are available for the zone.
Use the MENU buttons to scroll through all the different parameters.
In SOUND mode, both the Int Zone parameters and the Common parameters
without the inverse “S(Setup)” icon can be individually stored. (see page 55)
The Int Zone parameters can be stored as a SOUND of the MP6’s 256 SOUNDs.
The Common parameters can be stored as the initial settings in SOUND mode.
Zone parameters (Int) Zone parameters (Ext) Common parameters
Zone Mode Zone Mode Stretch Tuning
Sound (Int only) Trs Channel Temperament
Damper Resonance (Int Piano only) Trs PRG# Key of Temperament
String Resonance (Int Piano only) Trs Bank Select MSB LSB User Tuning
KeyOff Effect (Int Piano only) Keyboard On/Off Foot SW CC#
Voicing (Int Piano only) Velocity Dynamics EXP CC#
KeyOff Noise (Int EP only) Solo On/Off Modulation Wheel CC#
KeyOff Delay (Int EP only) Solo mode Left Pedal Mode
Tone Wheel Registration (ZONE1 Int Tone Wheel only) Damper Pedal On/Off/Hold Master Volume
Tone Wheel Percussion (ZONE1 Int Tone Wheel only) Footswitch On/Off
Tone Wheel Percussion Level (ZONE1 Int Tone Wheel only) Expression Pedal On/Off
Tone Wheel Percussion Decay (ZONE1 Int Tone Wheel only) Modulation On/Off
Tone Wheel Percussion Harmonics (ZONE1 Int Tone Wheel only) Bender On/Off
Key Click Level (Int Drawbar Organ only) Bender Range
EFX Type Key Range Hi/Lo
EFX parameter Velocity Switch On/Off
Amp Simulator On/Off (ZONE1 Int only) Velocity Switch Value
Amp Simulator Drive (ZONE1 Int only) Zone Transpose
Amp Simulator Level (ZONE1 Int only) Volume
Amp Simulator EQ Hi/Lo (ZONE1 Int only) Pan
Velocity Dynamics Fine Tune
Solo On/Off
Solo Mode
Damper Pedal On/Off/Hold
Foot Switch On/Off
Expression Pedal On/Off
Modulation On/Off
Bender On/Off
Bender Range
Key Range Hi/Lo
Velocity Switch On/Off
Velocity Switch Value
Zone Transpose
Volume
Pan
Fine Tune
Caution:
The edited settings will be erased when the power is turned off, or other sound is
recalled. To save these settings, use the STORE procedure to save them as a SETUP.
(see page 56)
