EN
2.9 Wire liners
Designed to suit specific filler wire materials and applications, Kemppi liners support the
filler wire and ensure reliable delivery to the welding arc. The liner selection tables describe
gun type, filler material, liner colour, item code and gun length. Steel spiral liners carry the
same colour coding as Kemppi machine feed rolls and drive rolls, making wire size, liner and
drive roll matching easier if the gun is connected to Kemppi equipment. Steel spiral liners are
suitable for welding solid and cored filler wires of corresponding wire diameter.
Kemppi DL Chili -Teflon liners are the latest solution for reliable feeding of aluminium, stainless
steel, acid-resistant and solid steel filler wires. Kemppi’s patented technology, two layer DL
Chili liner material significantly reduces friction losses between the filler wire material and
liner wall, ensuring reliable and worry-free feeding for listed wires types, even with guns up to
8 meters in length. Please refer to the following tables to ensure accurate selection of liners for
your chosen welding gun and application.
Wire liners for MMT, PMT guns
Steel/cored wire Filler wire ø, mm Order number, 3 m Order number, 4.5 m
0.6…0.8 4188571 4188572
0.9…1.2 4188581 4188582
1.4…1.6 (1.2) 4188591 4188592
1.6…2.0 4188601 4188602
2.0…2.4 4188611 4188612
2.8…3.2 4188621 4188622
Steel/Aluminium/
Stainless steel
Filler wire ø, mm Order number, 3 m Order number, 4.5 m
DL Chili 5.9/1.5 0.6…1.0 W005920 W005937
DL Chili 5.9/2.0 1.0…1.2 W005921 W005938
DL Chili 5.9/2.5 1.2…1.6 W005922 W005939
Aluminium
DL Chili 5.9/3.0 1.6 W007671 W007957
Wire liners for Weldsnake
Steel/Aluminium/
Stainless steel
Filler wire ø, mm Order number, 6 m Order number, 8 m
DL Chili 5.9/1.5 0.6…1.0 W005943 W005946
DL Chili 5.9/2.0 1.0…1.2 W005944 W005947
DL Chili 5.9/2.5 1.2…1.6 W005945 W005948
Aluminium
DL Chili 5.9/3.0 1.6 W007672 W007958
FastMig MXF 63, 65, 67
