25
ENGLISH
To “clone” (duplicate) the memory contents of one RC-18SR
into another RC-18SR or RC2000MK II , please follow these steps:
1. Place the source RC-18SR (the one with all of the customized
commands, names, macros, macro sequences, etc) with its
infrared transmitter window ¤1 facing the receiving infrared
sensor ¤2 of another “fresh” RC-18SR or RC2000MKII (5 cm, or 2
inches apart).
2. Press the CLONE button c of the source RC-18SR or
RC2000MKII with the tip of a paper clip, and select “CLONE TX”
(clone transmit) mode .
Note:
When using RC18SR, “RC2002” is displayed in LCD window. If
the receiving remote control unit is RC2000MKII , then the display
does not change. If the receiving remote control unit is RC-18SR,
then the display is changed to “RC18SR” by pressing the cursor
button ⁄6. (see Figure 20)
Figure 20
3. Press the CLONE button c of the learning (receiving) RC-18SR or
RC2000MKII with the tip of a paper clip or a similar object, and
select “
CLONE RX ” (clone receive mode).
When using RC18SR, “RC2002” is displayed in LCD window. If
the transmitting remote control unit is RC2000MKII , then the
display does not change. If the transmitting remote control unit is
RC-18SR, then the display is changed to “RC18SR” by pressing
the cursor button ⁄6. Then press the
PLAY button ⁄5.
Note:
When the transmitting remote control unit is RC2000MKII , then
All clone does not activate. To clone the Function key, press the
each Function key except DSS/VCR2 and AMP keys. Eight keys
can be cloned at once. If All clone activates without presing the
Function button, “N/A” will display and the clone is not perfomed
When the transmitting remote control unit is RC-18SR and
receiving remote control unit is RC2000MKII, The DSS/VCR2,
CD-R/MD and AMP keys cannot be cloned. To clone the
Function key, press each Function key except DSS/VCR2, CD-R/
MD and AMP keys.
Figure 21
4. Press the source RC-18SR’s or RC2000MKII’s transport control
PLAY ⁄ 5 button to begin the infrared data transmission
sequence. If you wish to duplicate only 1 to 8 function’s memory,
press the function button(s) you wish before pressing the PLAY
button. Now the “
LEARN ” indicator of receiving RC-18SR starts
to blink. (see Figure 23)
Figure 22 Figure 23
After all bars are lit up on both displays, “TX OK” (transmission OK)
will appear in the source RC-18SR’s LCD window, and “RX OK”
(reception OK) will appear in the “cloned” RC-18SR’s LCD window,
confirming the end of the copying process (see Figures 24 and 25).
Figure 24 Figure 25
Please be sure that, during the copying process, neither RC-18SR is
physically disturbed (ideally, they should be placed on a table or
other surface, and not hand-held during the copying process). If, for
some reason, the copying process was interrupted, the “clone” RC-
18SR’s LCD display window will indicate “RX NG” (reception no
good). Simply begin the clone process anew by repeating the above
steps.
Note:
Cloning is available between the same remote control unit series only
therefore the RC-18SR cannot be cloned by the RC2000.
5. If the source RC-18SR’s memory contents are at or near full
capacity, the copying process will take about 3 minutes. After
completion of the copying (cloning) process, press the
CLONE
button c on both RC-18SR’s with the tip of a paper clip, and
select the OFF mode.
Then, you’ll have two identically programmed RC-18SR remotes,
one of which can again be used as your system’s primary remote
control, and you’ll have the added confidence of knowing that in
the event of inadvertent programming (or memory contents being
cleared somehow), you can simply retrieve the “backup” RC-
18SR that you’ve safely tucked away, and within minutes restore
the programming contents of the original RC-18SR with your
customized configuration.
Note:
Some direct keys are marked “ ♦” in Direct Command Functions
Listing (page 27 to 30). The “ ♦” mark means as follows;
When RC-18SR is cloned with RC2000MKII, the name of the direct
key can be cloned, however the remote control code (the factory
preset code) cannot be cloned. Only learned remote control codes
can be cloned. Then the remote control code is learned by “LEARN
mode”. Refer to page 20.
The table of cloning relations
ALL OK: All functions can be cloned.
only FUNC.: The following functions cannot be cloned;
RC-18SR: DSS/VCR2, CD-R/MD, AMP
RC2000MKII: DSS/MD, AMP
LEARN
LEARN
Transmitting
Receiving
RC-18SR
RC2000MKII
RC-18SR
ALL OK
only FUNC.
RC2000MKII
only FUNC.
ALL OK
LOW NAME
