⑤ If the upper blades are not positioned to come into contact with the lower blades, remove
the perforator from the main body for adjustment.
⑥ Remove the perforator in the reverse order of the procedure described in (12) (How to
attach the perforator).
⑦ Loosen the two knurled head screws to remove the perforator cartridge cover.
⑧ Shift the perforator lock lever to the right. Loosen the clamp levers, move the perforator to
the desired position based on the scale, and tighten the clamp levers firmly.
⑨ Then, loosen screws with an accessory wrench and adjust the lower blade position to near
the center of the upper blades.
⑩ Put the perforator back on the main body and you are finished with this adjustment.
Caution
Avoid the combined use of the creaser and the
perforator, as it may cause a paper jam or a
mechanical failure.
Avoid contacting the cutting edge of the
perforating blade. Otherwise, injury could occur.
Lower Blade
Scale
Upper Blade
Hexagonal Wrench
Upper Blade
Perforator cartridge cover
Knurled head screw
Perforator lock lever
