USB-1208FS User's Guide Specifications
24
Counter
Table 14. Counter specifications
Parameter Specification
Pin name CTR
Counter type Event counter
Number of channels 1
Input type Schmitt trigger, 47 k
Ω pull-down to ground, rising edge triggered
Input source CTR screw terminal
Resolution 32 bits
Maximum input frequency 1 MHz
High pulse width 500 ns min
Low pulse width 500 ns min
Schmitt trigger hysteresis 1.01 V typ
0.6 V min
1.5 V max
Input high voltage threshold 2.43 V typ
1.9 V min
3.1V max
Input high voltage limit 5.5 V absolute max
Input low voltage threshold 1.42 V typ
1.0 V min
2.0 V max
Input low voltage limit -0.5 V absolute min
0 V recommended min
Non-volatile memory
Table 15. Non-volatile memory specifications
EEPROM 1,024 bytes
EEPROM Configuration Address Range Access Description
0x000 to 0x07F Reserved 128 bytes system data
0x080 to 0x1FF Read/write 384 bytes cal data
0x200 to 0x3FF Read/write 512 bytes user area
Microcontroller
Table 16. Microcontroller specifications
Parameter Specification
Type High performance 16-bit RISC microcontroller
