StrainBook/616 User’s Manual 968494 Specifications 12-3
Expansion Options
Item Description Number of
Channels
WBK10A voltage expansion chassis 8
WBK11A* simultaneous sample and hold (SSH) card for WBK10A 8
WBK12A* programmable Low-Pass Filter card for WBK10A 8
WBK13A* programmable Low-Pass Filter card with SSH for WBK10A 8
WBK15 isolated 5B signal conditioning module; 5B modules sold separately 8
WBK16/SSH strain gage expansion module with simultaneous sample and hold (SSH) 8
WBK16 strain gage expansion module (without SSH) 8
WBK17 Counter Input Module with Quadrature Encoder Support 8
WBK18 Dynamic signal conditioning module with Transducer Electronic Data Sheet
support (T.E.D.S.) 8
WBK40 Thermocouple Input Module 14
WBK41 Multi-function I/O module (14 channel T/C, 40 channel digital I/O, 4
counter-inputs, 2 timer outputs, optional: 4 analog output channels (see
description)
*
WBK11, WBK12, and WBK13 cannot be used directly with StrainBook. Each requires mounting within a WBK10A
if it is to be used in a StrainBook system.
Note: Specifications subject to change without notice.
