Programmable Features in WaveView
Channels can be configured through your own custom programs, third-party software such as DASYLab or
LabVIEW, or through the included out-of-the-box WaveView software. WaveView includes a Channel
Configuration screen (following figure) that allows you to turn channels on or off, select channel ranges,
change channel labels, and select engineering units.
Reference Note:
The WaveView document module contains more detailed information. Individuals who write
their own programs should refer to the readme.txt file [on the install CD-ROM] in regard to
the location of API reference material, including program examples.
Configuring Channels from WaveView’s Main Window
Selecting a Channel’s Range
You can use WaveView to select a channel’s range in one of two ways.
(1) Click in a channel’s Range cell; then select the desired range from the “Select Range”
pull-down list.
(2) Continue to double-click in the applicable channel’s Range cell to cycle through the
available ranges. Stop double-clicking when the desired range is indicated.
