gains—(DaqAdcGain)
Base Unit
Definition Description Applies to …
DgainX1 Main Unit-signal gain x 1 Daq products.
DgainX2 Main Unit-signal gain x 2 Daq products.
DgainX4 Main Unit-signal gain x 4 Daq products.
DgainX8 Main Unit-signal gain x 8 Daq products.
DgainX16 Main Unit-signal gain x 16
DaqBook/2000 Series, DaqLab/2000 Series, DaqScan/2000 Series ,
DaqBoard/2000 Series, DaqBoard/1000 Series and cPCI
DaqBoard/2000c Series products.
DgainX32 Main Unit-signal gain x 32
DaqBook/2000 Series, DaqLab/2000 Series, DaqScan/2000 Series ,
DaqBoard/2000 Series, DaqBoard/1000 Series and cPCI
DaqBoard/2000c Series products.
DgainX64 Main Unit-signal gain x 64
DaqBook/2000 Series, DaqLab/2000 Series, DaqScan/2000 Series ,
DaqBoard/2000 Series, DaqBoard/1000 Series and cPCI
DaqBoard/2000c Series products.
WgcX1 Main Unit-signal gain x 1 WaveBook products.
WgcX2 Main Unit-signal gain x 2 WaveBook products.
WgcX5 Main Unit-signal gain x 5 WaveBook products.
WgcX10 Main Unit-signal gain x 10 WaveBook products.
WgcX20 WBK Module - signal gain x 20 WBK11, WBK12, WBK13, and WBK14 .
WgcX50 WBK Module - signal gain x 50 WBK11, WBK12, WBK13, and WBK14 .
WgcX100 WBK Module - signal gain x 100 WBK11, WBK12, WBK13, and WBK14 .
WgcX200 WBK Module - signal gain x 200 WBK10A with WBK11, WBK12, or WBK13 installed; and WBK14.
DBK4-Filter
Definition Description
Dbk4FilterX1 DBK4-DBK4-LPF is on, signal gain x 1
Dbk4FilterX10 DBK4-LPF is on, signal gain x 10
Dbk4FilterX100 DBK4-LPF is on, signal gain x 100
Dbk4FilterX1000 DBK4-LPF is on, signal gain x 1000
Dbk4FilterX2 DBK4-LPF is on, signal gain x 2
Dbk4FilterX20 DBK4-LPF is on, signal gain x 20
Dbk4FilterX200 DBK4-LPF is on, signal gain x 200
Dbk4FilterX2000 DBK4-LPF is on, signal gain x 2000
Dbk4FilterX4 DBK4-LPF is on, signal gain x 4
Dbk4FilterX40 DBK4-LPF is on, signal gain x 40
Dbk4FilterX400 DBK4-LPF is on, signal gain x 400
Dbk4FilterX4000 DBK4-LPF is on, signal gain x 4000
Dbk4FilterX8 DBK4-LPF is on, signal gain x 8
Dbk4FilterX80 DBK4-LPF is on, signal gain x 80
Dbk4FilterX800 DBK4-LPF is on, signal gain x 800
Dbk4FilterX8000 DBK4-LPF is on, signal gain x 8000
DBK4-Bypass 1
Definition Description
Dbk4BypassX1_583 DBK4-LPF is off, signal gain x 1
Dbk4BypassX15_83 DBK4-LPF is off, signal gain x 10
Dbk4BypassX158_3 DBK4-LPF is off, signal gain x 100
Dbk4BypassX1583 DBK4-LPF is off, signal gain x 1000
Dbk4BypassX3_166 DBK4-LPF is off, signal gain x 2
Dbk4BypassX31_66 DBK4-LPF is off, signal gain x 20
Dbk4BypassX316_6 DBK4-LPF is off, signal gain x 200
Dbk4BypassX3166 DBK4-LPF is off, signal gain x 2000
Dbk4BypassX6_332 DBK4-LPF is off, signal gain x 4
Dbk4BypassX63_32 DBK4-LPF is off, signal gain x 40
Dbk4BypassX633_2 DBK4-LPF is off, signal gain x 400
Dbk4BypassX6332 DBK4-LPF is off, signal gain x 4000
Dbk4BypassX12_664 DBK4-LPF is off, signal gain x 8
Dbk4BypassX126_64 DBK4-LPF is off, signal gain x 80
Dbk4BypassX1266_4 DBK4-LPF is off, signal gain x 800
Dbk4BypassX12664 DBK4-LPF is off, signal gain x 8000
DBK7
Dbk7X1
DBK7- signal gain x 1 (Use with DBK55 also)
DBK8
Dbk8X1
DBK8- signal gain x 1
1 Bypassing the filter adds a hardware gain of x 1.583
