Nevion ETH1000-MKII - Manual (Page 3)

ETH1000-MKII Rev. A
nevion.com | 3
Contents
Revision history ........................................................................................................ 2
1 Product overview ................................................................................................... 4
2 Specifications ........................................................................................................ 5
2.1 Optical Characteristics .................................................................................................. 5
2.2 Ethernet ........................................................................................................................ 5
2.3 General ......................................................................................................................... 5
3 Configuration ......................................................................................................... 6
3.1 DIP control .................................................................................................................... 6
3.2 Multicon Gyda control .................................................................................................... 6
3.2.1 Block descriptions ...................................................................................................... 7
4 Connector module ................................................................................................. 8
4.1 Mounting the connector module .................................................................................... 8
4.2 Terminal format support ................................................................................................ 9
5 Module status ...................................................................................................... 10
5.1 Front panel – Status monitoring ...................................................................................10
5.2 GPI Alarm – Module status outputs ..............................................................................11
6 Laser safety precautions ..................................................................................... 12
General environmental requirements for Nevion equipment .................................. 13
Product Warranty.................................................................................................... 14
Appendix A Materials declaration and recycling information .................................. 15
A.1 Materials declaration ....................................................................................................15
A.2 Recycling information ...................................................................................................15
