21
Setup
Marine or Simulator
Inside, SD or Auto
Speed Filter
user's
Rotate Map
Remain Space
Oil Used Rate
destination
Enter the "Setup" column to review and set the manner as following :
System Mode:
Data Source:
: (continuously adjustable from 0 to 99 levels): The users may
set the filtering levels of the speed according to the needs, suggest that the larger
the winds and waves are, the higher the level is. The specific level can be set acc-
ording to the hull length and antenna height as well as the habits.
Time Zone: Enter the local time zone.
: Users may set up the charts display setting according to the needs,
that is, upper for the north, upper for the East, upper for the South, or upper for the
West.
: Indicate the remaining memory space after the storage of the
waypoints, routes, and tracks.
: Enter the fuel consumption to estimate the fuel needed to reach the
Time Format: Set to display 24-hour or 12 hours. see Figure 32
In/Out
Output NMEA0183, input and output the waypoints, the routes, and the tracks. At the
same time, the user may set it to be the different baud rate. See Figure 33
Press the MENU key to clear all the stored data and save all the data.
Figure 32 Figure 33
