Page 18 of 27 FRS-181 Owner’s Manual
• (V 2.1)
Menu Item Format Description
Frame Sync
Framesync Enable On/Off
Enables the Frame Sync
Horizontal Offset 0-4125 samples
Applies additional
horizontal offset
Vertical Offset 0-1124 lines
Applies additional vertical
offset
Minimum Latency
Frames
0-13
Selects the minimum
frames of latency allowed.
Video Audio Delay
Offset ms
(-575) - 575
Audio delay offset in
addition to delay to match
video delay.
Current Audio
Delay #.##ms / # Frames #
lines
Reports current audio
delay in both ms and
frames and lines.
Video Delay
#.##ms / # Frames #
lines
Reports current video
delay in both ms and
frames and lines.
Framesync Status On/Off/Error Shows the status of the FS
Reset Framesync Confirm
Resets the FS and its
buffers. Re-establishes
audio video sync after a
adjusting the horizontal
and vertical offsets.
Menu Item Format Description
Embedded
Audio Group
(Groups 1-4)
Group Enable
Enable Enables or disables the
entire group of 4 channels.
Disable
Source
(per channel)
Embedded 1-16 Chooses the source for the
embedded audio. The
source for each channel
can be chosen separately.
Dolby Ch. 1-8
Dolby Mix 1-2
Silence
Gain
(per channel)
Range (-400) – 400
Gain applied to embedded
audio output, one slider
for each channel.
Phase
(per channel)
Normal
Inverts the phase of the
embedded audio.
Invert
