Sim2 RS‐232 Control User Manual
Page 8
SUPERLUMIS
RS‐232 Control
8
Gamma
Action
Command
Response
Set Normal
BE EF 1A 0C 00 DC 4A 36 00 00 00 00 00 00 00 00 00 00 00
OK
20 XX 00
Set Dynamic
BE EF 1A 0C 00 10 8B 36 00 00 00 01 00 00 00 00 00 00 00
00 Natural
Set Param.
BE EF 1A 0C 00 05 CB 36 00 00 00 02 00 00 00 00 00 00 00
01 Dynamic
Get
BE EF 1A 0C 00 19 1B 36 00 01 00 00 00 00 00 00 00 00 00
02 Param.
Error
15 ..
In the response, XX is the hex representation of the value of Gamma.
Example: if the returned value is XX = 02 then Gamma is set to Parametric.
Overscan
Action
Command
Response
Increment
BE EF 1A 0C 00 91 52 04 00 02 00 00 00 00 00 00 00 00 00
OK
20 XX 00
Decrement
BE EF 1A 0C 00 54 03 04 00 03 00 00 00 00 00 00 00 00 00
Error
15 ..
Get
BE EF 1A 0C 00 9E A2 04 00 01 00 00 00 00 00 00 00 00 00
In the response, XX is the hex representation of the value of Overscan.
Example: if the returned value is XX = 0A then Overscan value is 10.
Lamp Power
Action
Command
Response
Set 290
BE EF 1A 0C 00 26 1C 25 00 00 00 22 01 00 00 00 00 00 00
OK
20 XX 01
Set 300
BE EF 1A 0C 00 AA 9d 25 00 00 00 2C 01 00 00 00 00 00 00
22
Set 310
BE EF 1A 0C 00 D9 1C 25 00 00 00 36 01 00 00 00 00 00 00
2C
Set 320
BE EF 1A 0C 00 D7 9B 25 00 00 00 40 01 00 00 00 00 00 00
36
Set 330
BE EF 1A 0C 00 A8 1B 25 00 00 00 4A 01 00 00 00 00 00 00
4A
Set 340
BE EF 1A 0C 00 28 9B 25 00 00 00 54 01 00 00 00 00 00 00
54
Set 350
BE EF 1A 0C 00 57 1B 25 00 00 00 5E 01 00 00 00 00 00 00
5E
Get
BE EF 1A 0C 00 E2 DE 25 00 01 00 00 00 00 00 00 00 00 00
Error
15 ..
In the response, YY XX is the hex representation of the value of Lamp Power.
Example: if the returned value is XX YY = 5E 01 then the Lamp Power value is 350W.
Variable Iris
Action
Command
Response
Set 0
BE EF 1A 0C 00 8B 23 58 00 00 00 00 00 00 00 00 00 00 00
OK
20 XX 00
Set 10
BE EF 1A 0C 00 F4 A3 58 00 00 00 0A 00 00 00 00 00 00 00
Error
15 ..
Set 20
BE EF 1A 0C 00 74 23 58 00 00 00 14 00 00 00 00 00 00 00
Set 30
BE EF 1A 0C 00 0B A3 58 00 00 00 1E 00 00 00 00 00 00 00
Set 40
BE EF 1A 0C 00 35 20 58 00 00 00 28 00 00 00 00 00 00 00
Set 50
BE EF 1A 0C 00 46 A1 58 00 00 00 32 00 00 00 00 00 00 00
Set 60
BE EF 1A 0C 00 CA 20 58 00 00 00 3C 00 00 00 00 00 00 00
Set 70
BE EF 1A 0C 00 91 A7 58 00 00 00 46 00 00 00 00 00 00 00
Set 80
BE EF 1A 0C 00 B7 26 58 00 00 00 50 00 00 00 00 00 00 00
Set 90
BE EF 1A 0C 00 C8 A6 58 00 00 00 5A 00 00 00 00 00 00 00
Set 100
BE EF 1A 0C 00 50 24 58 00 00 00 64 00 00 00 00 00 00 00
Get
BE EF 1A 0C 00 4E 72 58 00 01 00 00 00 00 00 00 00 00 00
In the response, XX is the hex representation of the status of the Variable Iris.
Example: if the returned value is XX = 5A then the Variable Iris value is 90.
