Sim2 RS‐232 Control - Manual (Page 9)

SUPERLUMIS
RS‐232 Control
9
3D Mode
Action Command Response
Set 2D BE EF 1A 0C 00 48 DE 59 00 00 00 00 00 00 00 00 00 00 00 OK 20 XX 00
Set 3D BE EF 1A 0C 00 84 1F 59 00 00 00 01 00 00 00 00 00 00 00 00 2D
Get BE EF 1A 0C 00 8D 8F 59 00 01 00 00 00 00 00 00 00 00 00 01 3D
Error 15 ..
In the response, XX is the hex representation of the status of the 3D Mode.
Example: if the returned value is XX = 01 then Mode is 3D.
3D Input Format
Action Command Response
Set Side by
Side BE EF 1A 0C 00 4C DA 5A 00 00 00 00 00 00 00 00 00 00 00 OK 20 XX 00
Set Top
Bottom BE EF 1A 0C 00 80 1B 5A 00 00 00 01 00 00 00 00 00 00 00 00 S‐S
Set Frame
Sequential BE EF 1A 0C 00 95 5B 5A 00 00 00 02 00 00 00 00 00 00 00 02 F‐S
Get BE EF 1A 0C 00 89 8B 5A 00 01 00 00 00 00 00 00 00 00 00 01 T‐B
Error 15 ..
In the response, XX is the hex representation of the value of 3D Input Format.
Example: if the returned value is XX = 01 then 3D Input Format value is Top Bottom.
3D Left/Right
Action Command Response
Set Normal BE EF 1A 0C 00 8F 27 5B 00 00 00 00 00 00 00 00 00 00 00 OK 20 XX 00
Set Swapped BE EF 1A 0C 00 43 E6 5B 00 00 00 01 00 00 00 00 00 00 00 00 Normal
Get BE EF 1A 0C 00 4A 76 5B 00 01 00 00 00 00 00 00 00 00 00 01 Swapped
Error 15 ..
In the response, XX is the hex representation of the value of 3D Left/Right.
Example: if the returned value is XX = 01 then 3D Left/Right value is Swapped.
Lens Zoom – Focus Calibration
Action Command Response
Zoom –1 BE EF 10 0B 00 AF C9 00 01 00 01 01 20 00 00 00 02 FF OK 1E BE EF 10 0D 00 3C C7 01 01 00 01 01 20 00 00 00 02 00 00 00
Zoom –10 BE EF 10 0B 00 A8 49 00 01 00 01 01 20 00 00 00 02 F5
1E BE EF 10 0D 00 3C C7 01 01 00 01 01 20 00 00 00 02 00 00 00
Zoom +1 BE EF 10 0B 00 AF C9 00 01 00 01 01 20 00 00 00 02 FF
1E BE EF 10 0D 00 3C C7 01 01 00 01 01 20 00 00 00 02 00 00 00
Zoom +10 BE EF 10 0B 00 E8 09 00 01 00 01 01 20 00 00 00 02 0A 1E BE EF 10 0D 00 3C C7 01 01 00 01 01 20 00 00 00 02 00 00 00
Focus +1 BE EF 10 0B 00 8F 4B 00 01 00 01 01 20 00 00 00 04 01
1E BE EF 10 0D 00 B4 C7 01 01 00 01 01 20 00 00 00 04 00 00 00
Focus +5 BE EF 10 0B 00 4C 4A 00 01 00 01 01 20 00 00 00 04 05 1E BE EF 10 0D 00 B4 C7 01 01 00 01 01 20 00 00 00 04 00 00 00
Focus –1 BE EF 10 0B 00 0F CA 00 01 00 01 01 20 00 00 00 04 FF
1E BE EF 10 0D 00 3C C7 01 01 00 01 01 20 00 00 00 02 00 00 00
Focus –5 BE EF 10 0B 00 0C 0A 00 01 00 01 01 20 00 00 00 04 FA 1E BE EF 10 0D 00 B4 C7 01 01 00 01 01 20 00 00 00 04 00 00 00
Error 15 ..
Memories
Action Command Response
Memory 1 Recall BE EF 02 06 00 A8 F2 A1 01 00 00 00 00 OK 20 XX 00
Memory 2 Recall BE EF 02 06 00 9B F2 A2 01 00 00 00 00 Error 15 ..
Memory 3 Recall BE EF 02 06 00 4A F3 A3 01 00 00 00 00
Memory 4 Recall BE EF 02 06 00 FD F2 A4 01 00 00 00 00
Memory 5 Recall BE EF 02 06 00 2C F3 A5 01 00 00 00 00
Memory 6 Recall BE EF 02 06 00 1F F3 A6 01 00 00 00 00
