Sloan 910 Royal Exposed 900 Hydraulic Series - Manual (Page 2)

2
MODEL 910/911
MODEL 986
MODELS 920/921/922 MODEL 980
CENTERLINE
OF FIXTURE
1-1/2” (38 mm)
OPENING
IN WALL
1” I.P.S.
(25 mm DN)
WATER SUPPLY
FIN.
FLOOR
FIN. WALL
4-3/4”
(121 mm)
11-1/2”
(292 mm)
MODEL 917
1-1/2”
(38 mm)
2-9/16”
(65 mm)
PUSH BUTTON
(LOCATION
OPTIONAL)
CENTERLINE
OF FIXTURE
1-1/2” (38 mm)
OPENING
IN WALL
1” I.P.S.
(25 mm DN)
WATER SUPPLY
FIN.
FLOOR
FIN.
WALL
2-1/4” (57 mm)
MIN.
4-3/4”
(121 mm)
11-1/2”
(292 mm)
1-1/2”
(38 mm)
2-9/16”
(65 mm)
PUSH BUTTON
(LOCATION
OPTIONAL)
6-1/2” (165 mm)
7-1/2” (191 mm) IF
2” (51 mm) SPUD
CENTERLINE
OF FIXTURE
1-1/2” (38 mm)
OPENING
IN WALL
1” I.P.S.
(25 mm DN)
WATER SUPPLY
FIN.
FLOOR
FIN. WALL
4-3/4”
(121 mm)
11-1/2”
(292 mm)
1-1/2”
(38 mm)
2-9/16”
(65 mm)
PUSH BUTTON
(LOCATION
OPTIONAL)
CENTERLINE
OF FIXTURE
1-1/2” (38 mm)
OPENING
IN WALL
3/4” I.P.S.
(20 mm DN)
WATER SUPPLY
FIN.
FLOOR
FIN.
WALL
2-1/4” (57 mm)
MIN.
4-3/4”
(121 mm)
11-1/2”
(292 mm)
1-1/2”
(38 mm)
2-9/16”
(65 mm)
PUSH BUTTON
(LOCATION
OPTIONAL)
1-1/2” (38 mm)
OPENING
IN WALL
1” I.P.S.
(25 mm DN)
WATER SUPPLY
FIN.
FLOOR
24”
(610 mm)
1-1/2”
(38 mm)
2-9/16”
(65 mm)
PUSH BUTTON
(LOCATION
OPTIONAL)
NOTE: Water Closet Valves with
“-2.4” Model Designation deliver 2.4
gpf (9.0 Lpf).
2-1/4” (57 mm)
MIN.
2-1/4” (57 mm)
MIN.
MODELS 913/915/916
CENTERLINE
OF FIXTURE
1-1/2” (38 mm)
OPENING
IN WALL
1” I.P.S.
(25 mm DN)
WATER SUPPLY
FIN.
FLOOR
FIN. WALL
4-3/4”
(121 mm)
(913): 16” (406 mm)
(915): 24” (610 mm)
(916): 27” (686 mm)
1-1/2”
(38 mm)
2-9/16”
(65 mm)
PUSH BUTTON
(LOCATION
OPTIONAL)
2-1/4” (57 mm)
MIN.
2-1/4” (57 mm)
MIN.
FIN.
WALL
CENTERLINE
OF FIXTURE
4-3/4”
(121 mm)
VALVE ROUGH-INS (NOTE: SPECIFY ACTUATOR VARIATION NEEDED FOR YOUR APPLICATION)
