3
Introduction
SPECIFICATIONS SPRAY STAR 1750D
WEIGHTS AND DIMENSIONS
Length 120" (305 cm)
Width 65" (165 cm)
Width With Boom Open 240" (610 cm)
Height w/ ROPS 77" (195 cm)
Height w/ Booms Folded 110" (279 cm)
Wheel Base 68" (173 cm)
Weight Empty 1750 lbs (794 kg)
Weight Full 3500 lbs (1588 kg)
SOUND LEVEL (DB)
At ear level 96 dBA
At 3 ft (0.914 m) 89 dBA
At 30 ft (9.14 m) 85 dBA
ENGINE
Make Briggs & Stratton
954T Turbo Diesel
Model# 58A447
Type / Spec# 0302E2
Horsepower 34 hp (25 kW)
Fuel No. 2 Diesel
Cooling System Liquid Cooled
Lubrication System Full Pressure
Alternator 40 Amp
WHEELS & TIRE
Front: Two 20 x 10.00 x 10 NHS Multi-Rib; 20 psi (1.4 bar)
Rear: Two 24 x 13.00 x 12 NHS Multi-Trac; 20 psi (1.4 bar)
SPEED
Infinitely Variable 0-12 m.p.h. (0-20 kph)
BATTERY
Automotive type 24F - 12 volt
BCI Group Size 24
Cold Cranking Amps 900 minimum
Ground Terminal Polarity Negative (-)
Maximum Length 10.25" (26 cm)
Maximum Width 6.88" (17 cm)
Maximum Height 10" (25 cm)
FLUID CAPACITY
Crankcase Oil See Engine Manual
Fuel 7 gallon (26.5 liters)
Hydraulic Fluid 5 gallon (19 liters)
Grade of Hydraulic Fluid SAE 10W-40 API Service SJ or highe
OPTIONAL EQUIPMENT
15-618 Water Meter Kit 15-493 18' Dry Boom
15-619 Chemical Cleanload 15-622 Canopy
17-505 Foam Marker 17-507 Manual Hose Reel
17-506 Clear water Wash Tank 17-521 Electric Hose Reel
17-503 20' Spray Boom 15-577 18' Manual Boom
10-300 18' Terrain Following Boom 30-003 20' Terrain Following Boom
14-515 Water Meter Kit (gallons) 15-618 Water Meter Kit (liters)
