83
Accessories
HOSE REEL PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HB-38-16-350 Bolt 3 /
8
- 16 x 3 1 /
2
2
HNTL-38-16 Lock Nut 3 /
8
- 16 2
2 14-325 Boom Carrier (part of machine) 2
3 10-221 Hose Reel Mount 1
4 16-906 Electric Hose Reel 1
16-129 Manual Hose Reel 1
5 18-249 Brass Fitting 3 /
4
MPT x 3 /
4
HB 1
6 HB-516-18-150 Bolt 5 /
16
- 18 x 1 1 /
2
4
HNTL-516-18 Lock Nut 5 /
16
- 18 4
7 HB-38-16-250 Bolt 3 /
8
- 16 x 2 1 /
2
2
HNTL-38-16 Lock Nut 3 /
8
- 16 2
8 16-295 Hose Fitting 1
1. Wear protective clothing when draining the tank and taking apart the lines.
2. Drain tank and spray system in a safe and approved method insuring that no chemical or water remain in
tank as you will be taking apart lines.
3. Remove key from ignition, set park brake and block wheels.
4. Remove square rubber covers on boom carriers.
5. Place hose reel bracket inside the boom carrier tube on left side and outside on right side with arms
pointing toward front of machine.
6. Lower bracket until top hole in bracket lines up with hole in upright. Bolt as shown.
7. Put hose reel on hose reel bracket with fitting on left side of machine. Use four bolts 5 /
16
- 18 x 1 1 /
2
and four
5 /
16
- 18 lock nuts to hold in place. Tighten bolts.
8. Put 18-249 barb fitting into hose reel.
(Continued on next page)
HOSE REEL ADJUSTMENTS
OPERATIONAL CHECK:
1. Pull hose off drum at least one full revolution. A clicking noise should be heard from locking mechanism.
2. Let the hose retract.
3. Pull the hose off until the first click is heard. Drum should lock when the hose tension is removed.
4. Continue pulling the hose, no more than one revolution, until no clicking is heard. Hose should rewind when
tension is removed.
HOSE REPLACEMENT PROCEDURE:
1. Facing swivel, turn the hose drum clockwise until all of the hose is removed from the drum and the drum is held
by locking mechanism. Make sure spring is locked.
2. Remove hose clamps and disconnect hose from swivel. Remove old hose.
3. Insert new hose through roller guide, connect to swivel and reinstall hose clamps. Use spring guard over hose
to protect the hose from being cut by the drum.
4. Remove check ball from old hose and install on replacement hose.
5. Carefully, keeping the tension on the hose, pull the hose to release the locking mechanism. Let the hose wind
on the drum.
