Tsunami SoundCar User’s Guide

Page 12

Step 2: Configuring the Decoder

The next CV you may want to customize is CV 29 (Configuration Register 1).

Customizing CV 29 requires setting its individual bit variables, as we briefly

addressed in the “Bits and Bytes” section of this manual. CV 29 is used in

conjunction with other CVs to set a multitude of decoder characteristics, such

as direction and alternate power source enable.

Table. B.

CV 29 – Configuration Register 1

Bit 7

Bit 0

MD

0

EAM

0

ACK

APS

F0

DIR

Primary or Extended Address (EAM) – Bit 5 (EAM) of CV 29 determines

whether the decoder will respond to the primary address in CV 1 or the

extended address in CVs 17 and 18 (see “Configuring the Address” for more

information).

Alternate (Analog) Power Source (APS) – Bit 2 (APS) of CV 29 allows the

decoder to work with an alternate power source (such as DC) when a DCC

signal is not present as set by CV 12 (Alternate Power Source).

Note: The SoundCar is shipped from the factory with analog mode disabled.

Table C, on the following page, lists the correct decimal value to program

into CV 29 for a variety of operating modes. To use the table, locate the row

with the operating characteristics you desire and program CV 29 with the

associated value.

Note: Table C values are in decimal format. If your command station requires

hex inputs, you will need to convert using Appendix A.

Refer to the Tsunami SoundCar Technical Reference for more CV 29

details.

Basic Programming
