Tsunami SoundCar User’s Guide Page 42
List of Configuration Variables (CVs)
The following is a quick reference list of CVs used by the SoundCar Digital
Sound Decoder. See the Tsunami SoundCar Technical Reference for
detailed information related to each CV.
Appendix B
CV 1 Primary Address Control
CV 3 Baseline Acceleration Rate
CV 4 Baseline Deceleration Rate
CV 7 Manufacturer Version ID
(read‑only)
CV 8 Manufacturer ID
CV 11 Packet Time‑out Value
CV 12 Power Source Conversion
CV 13 Analog Function Enable 1
CV 14 Analog Function Enable 2
CV 15 CV Unlock Register
CV 16 CV Lock ID Code
CV 17 Extended Address
CV 18 Extended Address
CV 19 Consist Address
CV 21 Consist Function Group 1
CV 22 Consist Function Group 2
CV 23 Consist Acceleration Rate
CV 24 Consist Deceleration Rate
CV 29 Configuration Register 1
CV 30 Error Information/
Alternate Mode Selection
CV 33 F0(f) Output Location
CV 34 F0(r) Output Location
CV 35 F1 Output Location
CV 36 F2 Output Location
CV 37 F3 Output Location
CV 38 F4 Output Location
CV 39 F5 Output Location
CV 40 F6 Output Location
CV 41 F7 Output Location
CV 42 F8 Output Location
CV 43 F9 Output Location
CV 44 F10 Output Location
CV 45 F11 Output Location
CV 46 F12 Output Location
CV 49 Headlight Effect Select
CV 50 Backup Light Effect Select
CV 51 FX5 Effect Select
CV 52 FX6 Effect Select
CV 57 FX5, FX6 Directional
Control Enable
CV 58 FX5, FX6 Lighting
Override Enable
CV 59 Flash Rate
CV 60 Crossing Hold Time
CV 61 F11 Braking Rate
CV 105 User Identifier #1
CV 106 User Identifier #2
CV 112 Sound Configuration 1
CV 113 Quiet Mode Time‑out Period
CV 114 Bell Ring Rate
CV 115 Airhorn/Whistle Select
CV 116 Moving Sound Scalar
CV 117 Rolling Stock Type Select
CV 118 Recovery Speed
CV 128 Master Volume Control
CV 129 Airhorn/Whistle Volume
CV 130 Bell Volume
CV 131 Clickety‑Clack Volume
CV 132 Generator Volume
CV 133 Flange Squeal Volume
CV 134 Flat Spot Volume
CV 135 Wheel Noise Volume
CV 136 Uncoupling Volume
CV 137 Coupler Volume
CV 138 Brake Set Volume
CV 139 Brake Squeal Volume
CV 140 Retainer Valve Volume
CV 141 Emergency Brake Valve Volume
CV 142 Hand Brake Set Volume
CV 143 Hand Brake Release Volume
CV 193 Bell ON Set Point
CV 194 Bell OFF Set Point
CV 195 Grade Crossing Airhorn/
Whistle Sensitivity
CV 197 Analog Mode Automatic
Sound Configuration
CV 198 DCC Mode Automatic
Sound Configuration
CV 201 Flange Squeal Probability
CV 202 Generator Probability
CV 227 Bell Select
CV 228 Intelligent Consisting Function
Output Location
