Version 1.0 Page 4 of 12 SMT80901_395VP20 User Manual
Outline description
The SMT8091_395VP is a single-C6416T based module (SMT395VP) combined
with a dual high-speed ADC module (SMT391-VP composed of SMT338-VP and
SMT391).
SMT395VP characteristics:
⇒
Single TMS320C6416T processor running @ 1GHz (32 bits)
⇒
Six 20MB/s communication ports (comports)
⇒
Up to 256MBytes of SDRAM @ 133MHz
⇒
8MByte Flash ROM for boot code and FPGA programming
⇒
Global expansion connector
⇒
General purpose I/O connector
⇒
High bandwidth data I/O via 2 Sundance High-speed Buses (32-bit SDB
interfaces)
⇒
8 Rocket Serial links @ 2Gbit/s per lane for inter-module communications
SMT391-VP characteristics:
⇒
Dual 8-bit ADC ( AT84AD001 ) sampling at up to 1Gsps via LVDS bus ( SLB )
⇒
Two Sundance High-speed Bus (SHB) connectors
⇒
Two 4-channel Rocket Serial Link ( RSL ) connector – 2.5Gbit/s per lane
⇒
Two 20 MBytes/s communication ports (comport)
⇒
Low-jitter on-board system clock
⇒
Xilinx Virtex-II Pro FPGA (VP30-6)
⇒
50-Ohm terminated analogue inputs and outputs, external triggers and
clocks via MMCX or MMBX (Huber and Suhner) connectors
⇒
User defined pins for external connections
⇒
Compatible with a wide range of Sundance SHB modules
⇒
TIM standard compatible
