Tri Tool 208B Sleeve Mandrel User Manual
Page 10
10
TRI TOOL INC.
92-1593 : Orig. 120221
Parts List, Mandrel Assembly, #1 Sleeve (P/N 06-0546)
12-0144
MANDREL SUBASSY,SLEEVE
1.
11-0139
ROD ASSY.,PUSH
1
2.
13-0573
MANDREL,SLEEVE,208B
1
3.
33-1527
SCREW,SET,1/4-20 X 1/4,HDOG
2
21-0295
HEAD ASSY,#1,SLEEVE MDRL.
4.
21-0301
HEAD #1,SLEEVE MDRL.
1
5.
33-0068
SCREW,CAP,3/8-16 X 5/8
3
6.
32-0015
PIN,ROLL,3/32 DIA X 5/16
3
46-0236
SLEEVE ASSY,#1
7.
24-0957
PLATE,BUTT,#1
1
8.
32-0038
PIN,ROLL 5/32 DIA X 1 1/2
1
9.
33-0482
SCREW,SET,#8-32 X 1/2 CUP PT
4
10.
46-0243
SLEEVE,MDRL,#1
1
Item
Part
No.
No.
Description
Qty
12-0144
MANDREL SUBASSY,SLEEVE
1.
11-0139
ROD ASSY.,PUSH
1
2.
13-0573
MANDREL,SLEEVE,208B
1
3.
33-1527
SCREW,SET,1/4-20 X 1/4,HDOG
2
21-0295
HEAD ASSY,#1,SLEEVE MDRL.
4.
21-0301
HEAD #1,SLEEVE MDRL.
1
5.
33-0068
SCREW,CAP,3/8-16 X 5/8
3
6.
32-0015
PIN,ROLL,3/32 DIA X 5/16
3
46-0237
SLEEVE ASSY,#2
7.
24-0958
PLATE,BUTT,#2
1
8.
32-0038
PIN,ROLL 5/32 DIA X 1 1/2
1
9.
33-0483
SCREW,SET,8-32 X 5/8 CUP PT
4
10.
46-0244
SLEEVE,MDRL,#2
1
Parts List, Mandrel Assembly, #2 Sleeve (P/N 06-0547)
Item
Part
No.
No.
Description
Qty
