7
Model 208B SM (Sleeve Mandrel)
92-1593 : Orig. 120221
SLEEVE MANDREL KIT RANGE
The Sleeve Mandrel setup will use the same instructions as the standard Mandrel.
Refer to the Model 208B BEVELMASTER
®
Operator’s Manual for complete
information for the standard Mandrel setup.
Min.
Max.
21-0295
46-0236
2.00" (50.8 mm)
2.30" (58.4 mm)
46-0237
2.44" (62.0 mm)
2.74" (69.6 mm)
21-0296
46-0238
3.20" (81.3 mm)
3.41" (86.6 mm)
21-0297
46-0239
3.70" (94.0 mm)
3.91" (99.3 mm)
21-0298
46-0240
4.20" (106.7 mm)
4.41" (112.0 mm)
21-0299
46-0241
5.24" (133.1 mm)
5.44" (138.2 mm)
21-0300
46-0242
6.30" (160.0 mm)
6.50" (165.1 mm)
21-0741
46-0671
8.27" (210.1 mm)
8.48" (215.4 mm)
Sleeve
Assembly
P/N
Head
Assembly
P/N
ID Range
ID MOUNTING RANGE
