13
Model 572AC SEVERMASTER®
92-0660 : Rev. 080423
The machine operation is finished when the tool holder returns home, release the lever
in order to turn off the motor.
Loosen the Collet by rotating the handle up.
Remove the pipe or tubing from the Model 572AC.
The tool holder will retract automatically in five (5) to ten (10) revolutions.
There is an audible ‘snap’ when the tool holder returns to the home position.
Observe the relationship between the pipe or tube and the tool bit.
The tool holder may be reset quickly by hand by rotating the cam feed knob to pick up
the feed slack.
It is not necessary to disengage the tripper shaft after each cutting operation.
