Model 572AC SEVERMASTER®
92-0660 : Rev. 080423
1.
19-0759
HOUSING, MAIN
1
2.
19-0761
HOUSING, FEED
1
3.
20-0632
SHAFT, MAIN
1
4.
20-0633
SHAFT, CLAMP
1
5.
20-0635
SHAFT, CAM
1
6.
20-0637
SHAFT, TRIPPER
1
7.
24-1479
PLATE, STAND
1
8.
24-1481
PLATE, CLAMP
1
9.
24-1482
PLATE, MAIN
1
10.
27-0556
ADAPTER, COLLET
1
11.
28-0256
O-RING
1
12.
28-0257
O-RING
1
13.
29-0031
BEARING, CAM FOLLOWER
1
14.
29-0348
BEARING, ROLLER
1
15.
30-0125
PLUNGER, BALL
1
16.
30-2490
CLUTCH, ROLLER
2
17.
32-0116
PIN, DOWEL, 1/4" DIA X 1/2"
2
18.
32-0140
PIN, DOWEL, 1/4" DIA x 3/4"
2
19.
32-0495
PIN, DOWEL, 5/16" DIA X 3/4"
1
20.
32-0497
PIN, STOP
1
21.
33-0013
SCREW, CAP, #6-32 X 1/2"
8
22.
33-0028
SCREW, CAP, #10-24 X 1/2"
8
23.
33-0031
SCREW, CAP, #10-24 X 7/8"
2
24.
33-0039
SCREW, CAP, 1/4-20 X 5/8"
4
25.
33-0489
SCREW, SET, #10-24 X 5/16", CUP PT
1
26.
33-0514
SCREW, SET, 5/16-18 X 3/8", CUP PT
2
27.
33-0954
SCREW, SET, #10-24 X 1/4", HDOG
2
28.
33-1391
EYEBOLT
1
29.
33-1979
SCREW, SHOULDER, 5/16" X 2"
1
30.
33-1985
SCREW, CAP, #10-32 X 1/2", BRASS TIP
1
31.
33-1986
SCREW, SET, 5/16-18 X 1/2", CONE PT
2
32.
33-1987
SCREW, SET, 5/16-18 X 3/4", HDOG
2
33.
--
Parts List, Model 572AC SEVERMASTER® Sub-Assembly (P/N 02-2221)
Item
Part
No.
No.
Description
Qty
